The Hybrid heat pump water heater with SAA, WATERMARK certifications.
Australian standard heat pump series, complied with the Small-scale Renewable Energy Scheme.
AS/NZS 4234 Water Heater Performance Evaluation.
Contact us to get the value of Small-scale Technology Certificates (STC) , the STC rebate will depend on your installation location.
*Theodoor heat pump has commissioned EnergyAE to evaluate the annual energy performance of the Theodoor 230L and 275L heat pump water heater system in order to determine the number of renewable energy certificate entitlements of the system under Australian rebate schemes.
▍Product Advantage
Air Source Water Heater, all in one design, double ventilation duct at top, high COP performance.
LED color display operation; three heating modes: AUTO, ECO (economic) and HEATER (fast heating) with timer setting. Full intelligent reverse defrosting and fault self-check. Intelligent control, the water temperature can be adjusted as needed and controlled by micro-computer automatically.
Apply brand compressor which is special used for air source heat pump. Built-in micro channel heat exchanger. The 360 degree supercharged foaming thickness reaches 50mm polyurethane insulation layer.
Easy installation: Vertical design, simple appearance, small foot space reduce working space.
Energy-saving& Environmental-friendly: Theodoor Air Source heat pump can make full use of natural heat, which realizes INEXHAUSTIBLE.There isn't any burning gas from the water heater. The refrigerant won't contaminate the ozonosphere. So it benefits the society.
Supply water anytime, and not be affected by geographical and weather changing. The water tank has larger capacity, constant temperature of great volume hot water, which meets the large demand of hot water for families.
Theodoor Air Source Water Heater
Double energy System by air-water technology and smart electric water integrated technology, to achieve a short period of time, all-weather, which means that using hot water, it is comfortable to enjoy the perfect combination of energy-saving design, it can used in the -15 ~ 43℃, anytime, anywhere to enjoy the hot water.
A Wide Range of Security Protection
Security Protection: ground fault circuit interrupter, leakage current checking, Ground Protection
Intelligent Protection System: protection of pressure voltage, motor overload protection, over-temperature protection
Safety Valve to Protect: Inside water temperature and pressure sensor, anyone value of more than security, it will be start relief
Hot water supply solutions
Theodoor heat pump water heater adopts central hot water supply design, which can meet various demands such as SPA, showering, washing, kitchen and balcony etc.
Theodoor heat pump work principle ：
The system follows carnot cycle principole. Driven by Electricity , its working substance absorbs the latent heat in the air or other low-temperature heat source , and waste heat let out of living or industry , compresses it to heat by compressor , exchange , exchange heat with water to higher the water temperature , 1 electricity can prduce heat equal to 4 electricity .it’s a new water heating equipment .
Energy Saving
Expenses comparison- 1 ton water to heat from 15℃ to 55℃
Name | Energy Source | Energy Price | Average Expenses |
Solar water heater and electronic auxiliary (Calculated for 90-120 days electronic auxiliary | Solar energy and electricity | Electricity 0.8RMB/Degree Free solar energy | 13RMB/Ton |
Diesel oil boiler | Diesel oil | 4.9RMB/Kg | 32RMB/Ton |
Fuel gas water heater | Gas | 6.0RMB/Kg | 39rmb/Ton |
Electrical water heater | Electricity | 0.8RMB/degree Free solar energy | 9RMB/Ton |
Environmental Protection
Heat comes from air, no exhaust gas produced. Protect our environment is social morality.
According to the study indicated that, for each unit of electricity ,the consumption of fossil material to about 0.67Kg of carbon dioxide release. China’s average temperature and a five-person households use hot water sa an example, one-year results of the air to water heater, carbon dioxide emissions can be reduced to 500kg, And save a few thousand dollars per year of liquefied gas and electricity costs .
Easy Install
Choose which sizes of water tank is related to the number of people using hot water, the number of bathrooms, whether there are bathtub, kitchens and other hot water consumption and so on.
The air source water heater unit has many installation ways, It can be installed at veranda, kitchen, storage room and garage etc.
Air source heat pump is not direct heating by the heating element, but with a small amount of electric driving the main unit's compressor to work, the low temperature air is compressed to high temperature air , through the pipeline circulation system to heat the water, the power consumption is only 1/4 of the traelectric water heater.
